Aluminum indoor panel

Products > INDOOR DOOH > Aluminum indoor panel

Indoor HD screen for all kinds of usages

Outdoor message sign		Value	Value	Value	Value
Physical parameter	LED Type	smd 0606	smd 3in1 0606	smd 3in1 1010	smd 3in1 1010
	Pixel Pitch(mm)	0.75	0.9375	1.25	1.875
	Panel dimensions(WxHxDmm)	480x270x50	480x270x50	480x270x50	480x270x50
	Pixel per panel	640x360	512x288	384x216	256x144
	Resolution ratio	16:09	16:09	16:09	16:09
	Panel weight(kg)	3.8	3.8	3.8	3.8
	Panel material	aluminum	aluminum	aluminum	aluminum
	Cabinet dimensions(WxHmm)	480x270	480x270	480x270	480x270
Optoelectrical Parameter	Brigtness(nits)	800-1200	800-1200	800-1200	800-1200
	Refresh rate(Hz)	≥7680	≥7680	≥7680	≥7680
	Gray scale(Bit)	16	16	16	16
	Contrast ratio	7500:1	7500:1	7500:1	7500:1
	Color temperature(K)	8000	8000	8000	8000
	Viewing Angle (H/V) (°)	160/160	160/160	160/160	160/160
	Driving Type	1/60	1/36	1/54	1/36
	AC Operating Voltage (V)	100-240	100-240	100-240	100-240
	Power Consumption (Max./Avg.)(W/panel)	150/70	150/70	150/70	150/70
Application Parameter	Storage Temperature (℃)	‑40~+60	‑40~+60	‑40~+60	‑40~+60
	Operating Temperature (℃)	‑30~+50	‑30~+50	‑30~+50	‑30~+50
	Storage Humidity (RH)	10%~90%	10%~90%	10%~90%	10%~90%
	Operating Humidity (RH)	10%~90%	10%~90%	10%~90%	10%~90%
	IP Rating (Front/Rear)	IP43	IP43	IP43	IP43
	Module Maintenance	Front	Front	Front	Front
	PSU & Others Maintenance	Front	Front	Front	Front
	Panel Installation Type	Fixed	Fixed	Fixed	Fixed
	Max Rigging QTY.	100	100	100	100
	Certificate	ETL	ETL	ETL	ETL
